Non Woven Fabrics MachineryWelcome to PPD Film Rewinder Machinery

The nonwoven cloth folding machine is widely used for automatic folding and cutting of nonwoven sheets.
The machine parts related to the product are made of 304 stainless steel.
The machine uses a high-quality frequency converter to control the speed, and the wiring of the electrical components is reasonable, beautiful and easy to operate.

Production process:
Nonwoven roll loading, synchronous conveying→vertical folding→horizontal fold→cutting and counting→finish product

Main technical parameters:

Name: Nonwoven cloth folding machine

Model: PPD-NWF530

Raw material size:600mm

Unfold size:600x530mm(LxW)

Folded size:265x150mm(LxW)

Applicable materials: Roll, 30-80g/m2, wood pulp composite nonwoven fabric, spunlace nonwoven fabric etc

Raw material width: OD≤ 1200mm, width 32mm

Raw material core diameter: Φ 76.2mm (=3")

Processing capacity: 200 pieces / minute

Total power required: 380V, 3.7kw

NOTE：Different sizes can be customized.
