Aluminium Foil MachineWelcome to PPD Film Rewinder Machinery

3 side seal aluminum foil roll packaging machine is a multifunctional model to pack aluminum foil roll, cling film roll, baking paper roll, and also any other daily commidity products.

Features:
1. Touch screen operation, intelligent system to control the parameters of the whole machine.
2. The feeding and paper feeding structure is controlled by servo to realize the function of stepless speed change, and the operation is simple.
3. The temperature of horizontal and vertical sealing is controlled independently, which is suitable for the packaging of different materials.
4. Linked film reeling shaft, uses multi-linked film reeling shaft to coordinate film pulling to suit more film materials.
5. Hot-press the central sealing area, heat the double-sided turntable to seal, and seal the back of the packaged product.
6. The end seal is cut, and the cutting knife is heat-sealed at a constant temperature to seal the front and back ends of the packaged product to prevent curling or air leakage

Main Data:

Name:3 Side Seal Aluminium Foil Roll Packaging Machine

Model: PPD-AFPM250

Film width: 240mm

Bag length: 300-450mm or as customized size

Bag making width: 30-110mm

Product height: 45mm

Roll film diameter: 320mm

Speed: 1-80 packs/min

Voltage: 220V, 50/60Hz

Power: 2.4kw

Machine size: 3685*665*1375mm(L*W*H)

Weight: 500kg

NOTE: Different sizes can be customized.
