Semi auto aluminum foil cling film rewinder PPD-SAAC600 is a multi-purpose model for rewinding both aluminum house foil rolls, and cling film rolls.
The machine is designed for 2 shaft automatic changing, it is very high speed, by automatic start of rewinding, when gluing is done by manual, all steps will be fulfilled automatically, include automatic stop when the set length is reached, automatic exchange on the shaft. automatically cut the finished roll.
The only manual work is for loading a new paper core, and unloading the finished roll.

Main technical data:

Name:Semi Auto Aluminum Foil Cling Film Rewinder

Model:PPD-SAAC600

Rewind material:Aluminum foil/cling film

Unwinding roll core diameter:3/6inch

Unwinding roll web width:maximum 600mm

Unwinding roll outer diameter:maximum 600mm or on request

Rewinding roll web width:maximum 620mm

Rewinding roll core inner diameter:25/35/38/40mm

Rewinding roll length set:3-300meters

Design speed:300m/min

Total power:2.5kw

Pneumatic supply:0.2Mpa

Weight:1000kg

Voltage: 220/240/380/415/450v

The machine is controlled by PLC programmer unit for very user friendly, the operation is only on click touch screen page.

It is adopted surface rewinding method, it can rewind for small length for consumer roll, and big length of 300meter(or more) for catering roll.

The machine has passed CE certificate for European Union safety requirement.ROHS certificate for environment friendly.

Different needs are available in customized model.
