Stretch Film RewinderWelcome to PPD Film Rewinder Machinery

The fully auto stretch film rewinder machine production line is a production line for containing 2units, 3 units or 4 units stretch film rewinder, carton sealer and includes a roller slide down table to convey the ready sealed carton to the pallet for easy loading .
There are two different types, L type and T type of production line for individual needs of consumers.
The machine is in high speed, fully automatic rewinding, automatic shaft changing, PLC man-machine interface communication program, touch screen operating for user friendly.
It is suitable for rewinding stretch film, industrial stretch, wrapping film, food cling film etc.

Technical Data:

Name:Fully Auto Stretch Film Rewinder Machine Production Line

Model:PPD-L500

Unwinding roll width:Max 500mm

Unwinding paper tube diameter: 3inch

Unwinding Diameter: max 500mm

Rewinding width: Max 500mm

Rewinding paper core diameter: 2inch.3inch(optional)

Rewinding Diameter: 300mm(max)

Rewinding speed: 1500rpm/min(max)

Total Voltage: 3phase,415v/380v/450v option

Total Power: 4.37kw

NOTE：Different sizes can be customized.
